Figure 6: XY-axis control producing dot and lattice patterns using two dyecontaining ST-gelatin solutions (dyes: malachite green and rose Bengal). Concentration of ST-gelatin, 10 wt. %; injection pressure, 0.1MPa; valveopening ratio, 1%; dispenser movement rate, 1 mm/s.
