Sphincterotomy Related Perforations Diagnosed by CT: Incidence, Risk Factors and Outcome

Michael Shapiro1#, Laurian Copel2#, Dov Abramowich1, Eitan Scapa1, Haim Shirin1* and Efrat Broide1

1The Kamila Gonczarowski Institute of Gastroenterology, Liver Diseases and Nutrition, Assaf Harofeh Medical Center, Sackler Faculty of Medicine, Tel Aviv University,Tel Aviv, Israel

2Department of Diagnostic Imaging, Assaf Harofeh Medical Center, Zerifin 70300, Israel

#Michael Shapiro and Laurian Copel contributed equally to this paper and should therefore be considered first authors.

*Corresponding Author:
Haim Shirin, MD
The Kamila Gonczarowski Institute of Institute of Gastroenterology
Liver Diseases and Nutrition
Assaf Harofeh Medical, Center, Zerifin 70300, Israel
Tel: +972-8-9779722
Fax: +972-8-9779727
E-mail: [email protected]

Received date: April 28, 2015; Accepted date: May 18, 2015; Published date: May 25, 2015

Citation: Shapiro M, Copel L, Abramowich D, Scapa E, Shirin H, et al. (2015) Sphincterotomy Related Perforations Diagnosed by CT: Incidence, Risk Factors and Outcome. J Gastrointest Dig Syst 5:288. doi:10.4172/2161-069X.1000288

Copyright: © 2015 Shapiro M, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

Visit for more related articles at Journal of Gastrointestinal & Digestive System


Duodenal perforation occurring during endoscopic retrograde cholangiopancreatography (ERCP) has been shown to cause high mortality. For assessment the incidence and risk factors of perforation after ERCP and determine the clinical outcome, an abdominal computerized tomography (CT) scan was performed in 180 patients undergoing therapeutic ERCP during three years. Demographic data, type of procedure (classical or pre-cut papillotomy), type of perforation (intra or retroperitoneal), laboratory tests, treatment, and outcome were evaluated.

Retroperitoneal perforation was detected in 21 patients (11.7%). Of these in four patients, perforation was retro and also intraperitoneal. Five patients in the perforation group died, two due to the procedure and three from unrelated causes. Patients who died were older than patients who remained alive. None of the patients with a retroperitoneal perforation underwent surgery, but one died from sepsis. Serum bilirubin levels were significantly higher in patients with perforation. Difficult or unsuccessful cannulation of the CBD and pre-cut papillotomy were found to be risk factors for perforation.

We suggest to perform an abdominal CT soon after therapeutic ERCP in elderly patients with high bilirubin levels in whom the ERCP was difficult or unsuccessful, or pre-cut papillotomy was needed. In patients with a retroperitoneal perforation, closer monitoring for signs of sepsis and/or peritonitis is required.


Sphincterotomy; Computerized tomography


Of all the gastrointestinal endoscopic interventional techniques, endoscopic retrograde cholangiopancreatography (ERCP) recorded the highest rate of complications with great variability. These include pancreatitis, bleeding, cholangitis and perforations [1,2]. Despite its low incidence, ranging from 0.3% to 1.3%, duodenal perforation occurring during ERCP has been shown to cause high mortality of 16–18% [2-9]. Several classifications of ERCP-related perforations have been published in the medical literature [9,10] and management guidelines based on clinical and radiological criteria have been developed [7-9]. However, the management of ERCP related perforations remains controversial: conservative versus early operative treatment [11,12].

There is no doubt that early and accurate diagnosis of perforations cannot be underestimated. It has been proposed that delayed diagnosis may result in dire outcome [3,7,9]. Abdominal computerized tomography (CT) is considered the best modality for the diagnosis of perforations [13]. In most studies, imaging was performed only in selective cases when a perforation was clinically suspected; either during the procedure or later on when clinical signs of perforation developed.

Our current knowledge regarding the incidence of ERCP related perforations remains scarce. Only two small series reported the results of routine CT examination after therapeutic ERCP. De Vries et al. [14] reported an incidence of 13% ERCP-related perforations (in three out of 24 patients), and Genzlinger et al. [15] reported an incidence of 29% (in six out of 21 patients). Despite the fact that most patients with routine CT-detected perforations had an uneventful course, these two studies with small number of cases do not provide us with any conclusive results for the appropriate management.

The objective of this study was to prospectively evaluate the incidence and risk factors of perforation in all patients undergoing therapeutic ERCP with a low-radiation abdominal CT and to assess the clinical outcome of these patients.

Patients and Methods

Between June 2005 and November 2008, 212 patients were recruited for the study. One hundred and eighty of them, mean age 63.7 years ± 17.7, 100 female, underwent classical or precut papillotomy. Patients younger than18 years of age, pregnant women and patients who were unable or unwilling to provide informed consent were excluded from the study.

Demographic characteristics, co-morbidities, history of upper gastrointestinal (GI) surgery or previous ERCP procedures were collected from all participants. Indications for ERCP and radiological reports were checked and all patients were closely followed until discharged from the hospital. The study was approved by the local ethics committee at our institution.


ERCP was performed by four experienced gastroenterologists, with a Pentax Duodenoscope (Tokyo, Japan). Vital signs were checked before, during and after each procedure. In all cases, cannulation of the common bile duct (CBD) was the preferred maneuver and when there was an indication for sphincterotomy, this was done after biliary cannulation and using a guide-wire technique. In those patients where cannulation of the CBD failed, a needle-knife pre-cut papillotomy was performed.

After the procedure was completed, the endoscopist graded the difficulty of the cannulation (grade 1 – easy, grade 2 – moderate and grade 3 – difficult). Access to the biliary tree was documented and clinical suspicion of perforation was recorded.

Diagnostic CT

All patients underwent a low-radiation abdominal CT after a median time of 48 minutes (range: 27 to 360 minutes) post ERCP. All scans were performed with a multi-detector CT (kVP 120, mAs 100) either Philips Brilliance 4 slices with slice thickness of 5.5 mm and slice interval of 5.0 mm (n=73) or 64 slices with slice thickness of 3.0 mm and slice interval of 3.0 mm (n=107) (Philips Medical Systems, MA, USA). No oral or intravenous contrast materials were administered.

Radiologic definition of perforation was as follows: any leakage of air or contrast material that was injected during the ERCP, regardless of the amount. Types of perforation as diagnosed by CT were classified as retroperitoneal(RPP), intraperitoneal (IPP) or combined. Our classification of RPP was based on a three-point scale: A) the mildest- with ≤5 small air bubbles in close proximity to the duodenum; B) air (>6 air bubbles) or contrast material around the duodenum and C) the most severe- large quantity of air (>6 air bubbles) or contrast material in the retroperitoneum, part of it noted remotely from the duodenum. IPP was classified on a two-point scale: A) ≤3 air bubbles noted in the peritoneal cavity and B) massive air noted in the peritoneal cavity.

Statistical Analysis

Numerical measurements are expressed using means±SD, with medians and ranges. Categorical measurements are expressed using percentages. Comparisons of sub-groups of patients with and without perforations included: 1) an independent t-test and the non-parametric Mann-Whitney test for the numerical data and 2) the chi-square test or Fisher's exact test for the categorical data. A multivariate logistic regression model was used in order to find out factors influencing perforation. A stepwise logistic regression analysis was conducted. All analyses were done using SPSS 14.01 statistical software (SPSS Inc., IBM Corp., NY, USA) A P value <0.05 was considered statistically significant.


A perforation was diagnosed by CT in 21 patients (11.66%): 17 patients (9.44%) had a RPP and four (2.22%) had a combined intra and RPP. No statistically significant differences between patients with or without a perforation were found regarding the indications for ERCP (Table 1), associated co-morbidities, cholelithiasis, previous cholecystectomy or other upper GI operations (Table 2). Approximately 50% of the patients underwent therapeutical ERCP for CBD stones and 24% for unexplained dilated CBD. Although not significantly a duodenal diverticulum tended to be more frequent in patients with a perforation than in those without (23.8% vs. 15.7%, respectively).

Variables All patients Without perforation With perforation, P value
n=180 n=159 (88.3%) n=21 (11.7%)
Common bile duct stones 94 (52.2) 84 (52.8) 10 (47.6)  0.095
Pancreatitis 7 (3.9) 7 (4.4) 0 (0)
Ca of pancreas/papilla 14 (7.8) 11 (7.0) 3 (14.3)
Dilated common bile duct 44 (24.4) 38 (23.9) 6 (28.6)
Cholangitis 14 (7.8) 13 (8.2) 1 (4.8)
Cholangiocarcinoma 1 (0.6) 0 1 (4.8)
Common bile duct leak 6 (3.3) 6 (3.8) 0 (0)
Papillotomy 125 (69.4) 119 (74.8) 6 (28.6) <0.001
Pre-cut 55 (30.6) 40 (25.2) 15 (71.4)
Stentingyes 55(30.6) 48 (30.2) 7 (33.3) 0.803
no 125 (69.4) 111 (69.8) 14 (66.7)
Accessyes 153 (85) 141 (88.7) 12 (57.1) 0.001
no 27 (15) 18 (11.3) 9 (42.9)
Easy 78 (43.3) 74 (46.5) 4 (19.0)
Moderate 47 (26.1) 42 (26.4) 5 (23.8) 0.004
Difficult 25 (13.9) 17 (10.7) 8 (38.1)
Impressionyes 8 (4.4) 3 (1.9) 5 (23.8) <0.001
no 140 (77.8) 128 (80.5) 12 (57.1)
Diverticulum yes 30 (16.7) 25 (15.7) 5 (23.8 ) 0.355

Table 1: ERCP variables, results are shown as: n (%).

Comorbidities, n (%) All patients
Without perforation
With perforation
P value
                IHD 44 (24.4 ) 38 (23.9 ) 6 (28.6) 0.600
                COPD 9 (5.0) 8 (5.0) 1 (4.8) 1.000
                Other* 46 (25.6) 41 (25.8) 5 (23.8) 1.000
Cholelithiasis 99 (55 0) 90 (56.6) 9 (42.9) 0.252
Cholecystectomy 55 (36 0) 50 (31.4) 5 (23.8) 0.617
Previous ERCP 39 (21.7) 34 (21.4) 5 (23.8) 0.782
Previous papillotomy 24 (13.3) 22 (13.8) 2 (9.5) 0.743

Table 2: Patient characteristics, IHD, ischemic heart disease; COPD, chronic obstructive pulmonary disease, *Diabetes mellitus, chronic renal failure, malignancy.

We found that the pre-cut technique was associated with a significantly higher rate of RPP compared to classical papillotomy (P < 0.001). Fifteen out of 21 patients (71.4%) with a perforation underwent pre-cut papillotomy in contrast to 40 out of 159 patients (25.2%) without a perforation. In patients with a perforation, no biliary access was achieved in 42.9% and in 38.1% the procedure was graded as difficult in comparison to 11.3% (P=0.001) and 10.7% ( P=0.004) respectively in patients without perforations.

In addition, in the group of patients with a perforation, 23.8% of the perforations were suspected by the gastroenterologist during the procedure, versus only 1.9% in the group of patients without perforations (P<0.001). No significant difference was found in the rate of perforations among the four endoscopists that took part in this study.

Imaging Findings

There was no case where a perforation was not detected in the initial CT study but diagnosed during the follow-up CT study. Among 17 patients with RPP, the findings were as follows: six patients (35.3%) had a type A (Figure 1), six patients (35.3%) a type B (Figure 2), and five patients (29.4%) had a type C perforation (Figure 3).


Figure 1: Type A retroperitoneal perforation. Axial CT discovered tiny air bubbles (arrow) between the duodenum, the head of the pancreas and the inferior vena cava.


Figure 2: Type B retroperitoneal perforation. CT demonstrated a stent in the duodenum (arrow-head) and a moderate amount of air and contrast material laterally to the second part of the duodenum (arrow).


Figure 3: Type C retroperitoneal perforation. CT demonstrated free air anterior to the pancreas in the lesser sac.

In four patients, an intra and extraperitoneal perforation was found. Three of them had type B IPP with massive intraperitoneal air (Figures 4a and 4b) and in one patient only a minimal quantity of air was found in the intraperitoneal cavity defined as type A IPP perforation. All patients with IPP also had a large quantity of retroperitoneal air (type C RPP).


Figure 4a: Massive intraperitoneal perforation (type B); a) CT slice at the level of the upper abdomen demonstrated a large quantity of free intraperitoneal air anterior to the liver and stomach (arrows).


Figure 4b: CT slice at the level of the pancreatic head demonstrated a large quantity of free intraperitoneal air (arrow) and a retroperitoneal contrast leak from the junction of the second and third part of the duodenum (arrow-head).

Laboratory Findings

There were no significant differences between the two groups except in the levels of bilirubin. Total and direct bilirubin before ERCP were significantly higher in patients with post ERCP perforation [total bilirubin 5.4 ± 5.5 4 mg/dL (4.0; 0.3-37.8); direct 4.4 ± 4.14 mg/dL (3.3; 0-23) in patients without perforation compared to 9.9 ± 7.54 mg/dL (14.4; 0.4-23.2) and 8.3 ± 5.84 mg/dL (6.9; 0-17) in those with perforation (P=0.001). The total bilirubin level decreased 24 hours after ERCP from 5.4 mg/dL to 4.6 mg/dL in patients without perforations, and increased from 9.9 mg/dL to 10.4 mg/dL in those with perforations (P=0.027).

Clinical Management and Mortality

Blood pressure, heart rate and oxygen saturation were not significantly different between patients with or without perforation, before and after papillotomy. All patients with a perforation were treated conservatively by fasting and the administration of nasogastric tube, IV fluids and antibiotics. Worsening abdominal pain, leukocytosis or sepsis led to surgery. None of the patients with a RPP underwent surgery, regardless of the type of perforation. Two out of four patients with an IPP underwent surgery due to signs of peritonitis.

One patient out of 159 patients without perforations died from post ERCP pancreatitis. Overall, in the group of patients with perforations, five patients died. Of these two patients died from direct ERCP-related causes, and three from indirect ERCP related complications. Three of the patients had RPP and two patients had combined IPP and RPP (Table 3). One the patients developed sepsis with no abdominal tenderness on the fifth day after the ERCP. A second CT scan (this time with IV contrast material administration) demonstrated a retroperitoneal abscess. She was treated conservatively, but died from sepsis 20 days later. Two other patients died from causes unrelated directly to the perforation such as MI and pancreatic cancer. Two out of four patients with combined perforation died, one after surgery and the other, who was treated conservatively, due to pulmonary edema.

Patient  1 2 3 4 5
Age 80 87 74 88 84
Type of perforation RPP RPP RPP Combined Combined
Treatment Conservative Conservative Conservative Surgery Conservative
Cause of death ERCP MI PC ERCP CHF

Table 3: Deceased patients in the perforation group. RPP; retroperitoneal perforation, IPP; intraperitoneal perforation, CHF: Congestive heart failure; MI :myocardial infarction, PC: pancreatic cancer.

Patients who died were significantly older than those that stayed alive 59.9 ± 14.6 (63.5; 21-81) years vs. 82.6 ± 5.7 (84; 74-88) years and this difference was significant despite a small cohort size (Kruskal-Wallis test with a P value of 0.003). There was no difference in the rate of comorbidities, values of laboratory tests, cannulation difficulty grade, access to the biliary tree or clinical suspicion of perforation.

Multivariate Logistic Regression Analyses

Multivariate logistic regression analyses were performed using all the significant and some of the non-significant perforation factors that were received from univariate analysis (Table 4). After using the stepwise method, only three factors were found to have a significant risk effect on perforation: lower aspartate aminotransferase (AST) level before the procedure, pre-cut papillotomy and the endoscopist's impression.

Variables in the equation OR (95% CI) P value
Step 1 Gender 1.86 (0.13-25.98) 0.645
Age 0.91 (0.83-1.01) 0.067
Previous ERCP  3.52 (0.12-105.17) 0.468
Previous Papillotomy 0.25 (0.00-60.07) 0.618
Bilirubin level 0.43 (0.17-1.06) 0.067
AST 0.99 (0.95-1.02 0.449
ALT 1.00 (0.98-1.03 0.694
ALP 1.00 (0.98-1.02 0.956
Dilated CBD 0.86 (0.00-457.4) 0.963
CBD diameter 0.88 (0.57-1.34) 0.537
Diverticulum 0.72 (0.02-30.7) 0.866
Pre-cut 13.99 (0.36-543.5) 0.158
Difficulty 1.93 (0.09-42.7) 0.677
Access 0.53 (0.03-11.3) 0.687
Impression 1731.7 (7.00-428253.1) 0.008
Endoscopist 21.00 (0.47-942.3) 0.116
Gender 1.86 (0.13-25.98) 0.645
Variables in the equation OR (95% CI) P value
Step 20 AST 0.98 (0.97-0.99) 0.009
Pre-cut 14.61 (3.15-67.77) 0.001
Impression 43.43 (3.10-609.06) 0.005

Table 4: Risk factors for perforation by multivariate stepwise logistic regression. ALT: alanine aminotransferase; ALP: alkaline phosphatase; AST: aspartate aminotransferase; CBD common bile duct.


Our results, with the largest cohort of patients published until now, indicate that the actual incidence of all types of ERCP-related perforations (symptomatic, asymptomatic, RPP and IPP) is high- 11.66% (9.44% RPP and 2.22% IPP). We also identified exclusively increased RPP rate in patients who underwent pre-cut because of difficult and unsuccessful cannulation of the biliary tree and in patients with high bilirubin levels (total and direct). These results are consistent with previous reports, that also showed high (13% and 29%) post ERCP asymptomatic perforation rates [14,15] although recent meta-analysis suggests that pre-cut sphincterotomy and persistent attempts at cannulation are comparable in terms of overall complication rates [16].

Usually, a perforation is suspected by the endoscopist during or after the procedure based on leakage of contrast material from the duodenum or the biliary tree, clinical signs and symptoms such as abdominal pain, leukocytosis, or sepsis. In many centres, special attention is paid to this risk by making a plan abdominal X-ray as the last step of the procedure after sphincterotomy. Consequently, in the large majority of cases with symptomatic RPP this complication is detected during the procedure [17]. However, the clinical significance of asymptomatic perforation is not entirely clear. The consensus in the last two decades assume that type II and III injuries mostly, tend to seal spontaneously and thus lend themselves to nonsurgical management [10,18]. Moreover, Genzingler et al. hypothesized that retroperitoneal air alone (type IV) is probably related to the use of compressed air to maintain patency of a lumen [15]; as such, it is not a true perforation and thus does not require surgical intervention. Indeed only lateral or medial wall perforations (type I) that are caused by the endoscope, tend to be large and require immediate surgery [19].

Nevertheless, by contrast to previous studies suggesting that RPP has little clinical significance [20], two patients with asymptomatic RPP in our study died from indirect causes, compared to none in the group of patients without a perforation. Three patients (1.7%) in our series died from direct ERCP-related complications: two from the perforation group and one from the "non perforation" group. Three additional patients died from indirect causes, and all three were in the perforation group. Four of the dead were octogenarians and old age was the only significant factor that differed between the patients with perforation who died and those who survived. As previously emphasized post ERCP cardiopulmonary complications are significantly higher in patients older than 65 years compared with younger than 65 [21]. Therefore we assume that the significance of perforation probably sprawls beyond local inflammation. It might be speculated that stress concerning the procedure, inflammatory mediator secretions related indirectly to the procedure and systemic complications may be involved in their death.

We believe that early diagnosis of perforations is crucial for proper treatment of patients after therapeutic ERCP. Moreover, early abdominal CT would enable early diagnosis of IPPs regardless of clinical signs. We demonstrated that CT can be performed immediately after therapeutic ERCP with no need for preparation (oral or intravenous contrast material). In our study CT diagnosed all of the ERCP-related perforations on the initial early scan with no additional diagnosis of perforation on a follow-up examination. We did not use the classification that was introduced by Stapfer and colleagues [10]. They made a diagnosis during the ERCP or performed imaging tests (usually upper GI swallowing) only in patients in whom perforation was suspected clinically. We used our own classification based on CT findings and found it to be a simple and useful tool for the clinician.

In addition, in this prospective study we evaluated the risk factors of such perforations. We knew that pre-cut papillotomy and failed CBD cannulation are both associated with an increased complication rate [1,2,4] such as bleeding, pancreatitis and symptomatic perforation. By using logistic regression multivariate analysis, pre-cut papillotomy and the endoscopist's suspicions were identified as risk factors for perforation Interestingly, a higher AST level before the procedure was found to be a protective factor.

We are aware that our study has several limitations. The rate of perforations, including clinically significant and even fatal ones, was high compared to the literature [22]. The volume of ERCP procedures during the years of the study was relatively small. Freeman et al. have already shown, that complications of ERCP, especially severe ones, are related to the volume of procedures peformed by the endoscopist [23]. This also may explain the exceedingly high rate of pre-cut papillotomy (31%) among our patients requiring sphincterotomy. Despite this, our current incidence of perforations on CT was less than those of De Vries et al. (13%) and Genzlinger et al. (29%) [14,15]. Finally, our surgeons were not blinded to the result of the CT due to ethical reasons. However, this did not alter the treatment modality or the clinical course as only conservative treatments were applied for these patients.

In conclusion, based in our findings we suggest to perform an abdominal CT soon after therapeutic ERCP in elderly patients with high bilirubin levels in whom the ERCP was difficult or unsuccessful, or pre-cut papillotomy was needed. In patients with a RPP, closer monitoring for signs of sepsis and/or peritonitis is required.
