High Tmperature Energy Materials Centre, Korea Institute of Science and Technology, 39-1 Hawolgok, Seongbuk, Seoul 136-791, South Korea
Received Date: September 05, 2013; Accepted Date: October 04, 2013; Published Date: October 11, 2013
Citation: Biswas M (2013) Electrolyte Materials for Solid Oxide Fuel Cell. J Powder Metall Min 2:117. doi: 10.4172/2168-9806.1000117
Copyright: © 2013 Biswas M. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Visit for more related articles at Journal of Powder Metallurgy & Mining
The first criterion for the electrolyte of solid oxide fuel cells (SOFC) is to have sufficient ionic conductivity without any significant electronic conductivity. Since the cell operates at high temperature, it must withstand that operating temperature along with stability in both reducing and oxidizing environments. It must be impermeable to gas to prevent mixing between fuel and oxidizer before they reach to the reaction sites. There are two groups of electrolytes based on their ion conducting phenomenon. They are oxide ion conducting and proton conducting. Oxide ion conducting materials are widely used. Therefore, the primary focus is given on these materials.
Oxygen ion conductors; Zirconia; Ceria; Proton conductors
The electrolyte is the central part of a Solid Oxide Fuel Cell (SOFC), which is sandwitched between cathode and anode. The oxygen ions (O2-) reduced on cathode or proton (H+) oxidized on anode sides is transported through the electrolyte materials and reacts with hydrogen or oxyegen, respectively, to form water on either side of the cell. The electrons (e-) generated due to the reaction pass in the opposite direction through the outer circuit . There are two types of materials: oxide ion and proton conducting electrolytes.
Its electronic conductivity must be kept as low as possible to prevent losses from leakage currents. The high operating temperatures of SOFCs allow the kinetics of oxygen ion transport to be sufficient for good performance. However, as the operating temperature approaches the lower limit for SOFCs at around 600°C, the electrolyte begins to have large ionic transport resistances and affect the performance. Popular electrolyte materials include yttrium stabilized zirconia (YSZ) (often the 8% form Y8SZ), scandia stabilized zirconia (ScSZ) and gadolinium doped ceria (GDC) . Materials choice for this purpose is difficult because attention must be paid to many parameters such as gas tightness, electronically nonconducting, chemical stability over a wide oxygen partial pressure (1-10-21 atm) and temperature range, good bending strength etc .
Materials for electrolyte of solid oxide fuel cell
The basic reactions for the generation of electricity directly from electrochemical reaction are given below:
For oxide ion generating reaction:
1/2 O2 + 2e- = O2-
H2 + O2- = H2O + 2e-
2H2 + O2 = 2H2O (1)
The reaction of hydrogen and oxygen is an exothermic one that produces heat about 57 kcal per mole of reactant.
For proton generating reaction:
H2 = 2H+ + 2e-
1/2 O2 + 2e- = O2-
2H+ + O2- = H2O (2)
Electrons generated from the above reactions flows through the outer circuit so as to provide electricity .
Oxide ion conducting electrolytes
Oxide ion conducting electrolytes cover a wide range of materials which basically include fluorite-, perovskite-, brownmillerite- structured materials.
This structure is adopted by ceria at room temperature and zirconia at high temperature. Basically zirconia and ceria based materials are widely investigated for its application as electrolyte in solid oxide fuel cell (SOFC) . Zirconia is stabilized to its cubic structure at room temperature by the addition of divalent and trivalent cations [5,6]. Ceria forms solid solutions with many divalent and trivalent cations which show fluorite structure at room temperature and takes part in ionic conduction . Yittria stabilized zirconia is not the best ionic conductor . Bismuth oxide-based materials, ceria-based materials and strontium doped lanthanum oxide show better conductivity than showed by zirconia-based materials. T. Takahashi et al reported the same about bismuth oxide-based materials . Among all these materials δ-Bi2O3 has an oxygen deficient fluorite structure where 1/4th the normal fluorite anion sites are vacant. This is the reason for its very high conductivity. But the drawback of this material is that it suffers from chemical instability. It is of monoclinic structure at room temperature, but cubic at high temperature. It gets readily reduced at low oxygen partial pressure and decomposes into bismuth metal at oxygen partial pressure of about 10-13 atm [10,11]. Therefore, the practical use of bismuth oxide as electrolyte of SOFC is under serious question. So it is better to go for ceria and zirconia-based materials for the application as electrolyte in SOFC.
Zirconia-based oxide ion conductors
The solid electrolytes to be used for high temperature fuel cell should have a good number of properties such as high oxide ion conduction with negligible electronic conductivity, phase stability, non-porous, good mechanical strength, thermal shock resistance, chemical inertness to the reactive gas, compatibility with electrode in the view of thermal expansion coefficient and chemical inertness towards the electrodes. These requirements are sufficiently fulfilled by doped zirconia. Addition of some rare earth, alkaline earth and lanthanide oxides stabilizes monoclinic zirconia to cubic fluorite phase at room temperature; moreover, this addition enhances ionic conductivity to an extended oxygen partial pressure range of SOFC operation. This range covers 1 to 10-18 atm pressure which an SOFC electrolyte has to face at the anode side during operation at high temperature while other renowned electrolyte, doped ceria, fails due to its electronic conduction and poor mechanical strength. The oxides which have come to the forefront for their use as dopants for zirconia are calcia (CaO), magnesia (MgO), scandia (Sc2O3) and yittria (Y2O3). Stabilized zirconia is stable over wide temperature range, in this range ionic conductivity is independent of oxygen partial pressure over several orders of magnitude [12,13]. Yittria stabilized zirconia (YSZ) shows electronic conductivity at oxygen partial pressure of 10-30 atm which is far below the pressure range of 0.21 - 10-20 atm during the operation of SOFC . Its oxygen transference number is one over a wide range of temperature and oxygen partial pressure .
From Table 1, considering the resistivity data it can be concluded that calcium is not a better dopant than yittria. It has been established that clusters comprising of two oxygen vacancies at the opposite ends of a body diagonal in one of the anion cubes of the fluorite structure exist throughout the body. It is presumed that this vacancy dimmer is stabilized by trivalent ions . The association is called cluster. It is assumed that these clusters exist in a group, not in isolation. In some cases ordered phases (Ca2Zr4O9) get precipitated out, but still there is a controversy [15-17]. There are also evidences for short range order. As for example, Yittria doped zirconia shows short range order . The site exclusion principle states that the presence of a cluster at a site prevents other clusters from occupying adjacent sites in the lattice .
at 800 °C (Ocm)
|Resistivity at 1000 °C (Ocm)|
Table 1: Resistivity data of doped ZrO2.
Literature reported that conductivity increases with dopant concentration upto a certain amount which is required to fully stabilize monoclinic zirconia to its cubic fluorite structure . Conductivity decreases with further addition of dopant. This decrease can be explained in terms of dopant-vacancy interactions. For low dopant concentration, the aliovalent ions will be isolated in the host cation sites and very few of them will share a common oxygen site. Therefore, the interaction between dopant ions and oxygen vacancies leads to the formation of shor range clusters which can be described as dopant-vacancy complex, while the other dopants will bear effective negative charge compared to zirconium ion. As for example, one half of the dopant ions will be in cluster with oxygen vacancies since two yttrium ions produce one oxygen ion vacancy. Since this cluster formation process is reversible, dissociation of this complex also occurs. When concentration of dopant increases the probability of formation of a cluster containing two dopants with a single oxygen vacancy gets enhanced. This cluster acts as trap due to coulombic interaction. So, the mobility of oxygen vacancies gets reduced [19,20]. Yittria is widely used as the stabilizer for zirconia because of its abundance and cost effectiveness compared to other dopants . Scandia and ytterbia have also found application due to their better ionic conductivity; but yttria doping is widely used due to the above mentioned reasons. Literatures report that 8 - 10.5 mol% yittria stabilizes zirconia to its cubic structure . Literature also reported the doping of zirconia with more than one cations instead of only one cation [22,23]. As for example, such compositions are zirconia doped with yittria (Y2O3), scandia and ytterbia (Yb2O3) (composition 1), zirconia (ZrO2) doped with yittria (Y2O3), dysprosia (Dy2O3) and ytterbia (Yb2O3) (composition 2). All the dopants were chosen on the basis of their radius according to the Hume Rothery rule . To achieve maximum solid solubility, the atomic radii of the solute and solvent atoms must differ by no more than 15%. The maximum Electrical conductivities were 0.18 and 0.16 S/cm for compositions 1 and 2, respectively, with the combined dopant concentration of 8.3 mol% at 1000°C . Bending strength is another important factor to maintain mechanical integrity and to withstand thermal stress with other components of the cell. It was about 100 MPa for those compositions, which does not suffice the need at the operating temperature of SOFC. On the other hand, yittria stabilized zirconia is a promising candidate, in this regard too, with the bending strength of 400 MPa . Thermal expansion is another factor to be considered. Zirconia stabilized with 8 mol% yttria exhibits a very consistent coefficient of thermal expansion of 10.5x10-6/K from 25°C to 1000°C .
Ceria-based oxide ion conductors
Ceria-based materials have found potential application as electrolyte materials for the intermediate temperature (500-750°C) solid oxide fuel cell (ITSOFC) . ITSOFC is favourable compared to high temperature SOFC. Several advantages are obtained with the reduction in operating temperature; they are: less prone to thermal and mechanical stress, wide range of materials selection, short startup time, easy maintenance, better thermal management, much more economic, reduced effect of thermally activated processes . A descriptive study was carried out on a series of ceria compositions; CaO, SrO, MgO and BaO have been used as dopants . The result shows that CaO and SrO enhances electrical conductivity to a great extent but MgO and BaO do not enhance so far. Literature reported the effects of rare earth oxides (such as Sm2O3, Gd2O3 and Y2O3) as dopant in ceria on electrical conductivity . The observation led to the conclusions that doping with Sm3+ among rare earth oxides and Ca2+ among alkaline earth oxides produces maximum conductivity. The problems associated with ceria based materials are that they are prone to reduction at low oxygen partial pressure, which is prevalent on the anode side of SOFC, that leads to electronic conductivity  and possible large mechanical disintegration under large oxygen chemical potential gradients typical of SOFC operation [31,32]. This problem can be solved by decreasing operating temperature to below 650° to 700°C. Enumerable work has been carried out by different research groups to get rid of this problem. But there was no solution without yittria stabilized zirconia. Ceria based materials are mechanically very weak. Yahiro et al and Mehta et al deposited a thin film of yittria stabilized zirconia (YSZ) on ceria-based materials on anode side to suppress electronic conduction [33,34]. But the problem occurs with the operating temperature; ceria based electrolytes are used in SOFC operated at 550°C and lower whereas YSZ thin film can work only at higher temperature to suppress electronic conduction . So the problem has to be addressed further to have proper solution. Another solution is that doped ceria can be used with doped lanthanum gallate in multilayer cells [31,32]. But this multilayer electrolyte shows very poor performance due to formation of new layer caused by inter-diffusion at the boundary of YSZ and ceria, which, in turn, causes low ionic conduction . This layer may introduce thermal expansion mismatch at the operating temperature, resulting into microcracks [33,36]. At reduced operating temperature, the overall cell voltage will be lower due to critical polarization resistance of electrodes, rendering poor cell performance, non-uniform current and/or distribution of reaction rate throughout the electrolytes may cause local heating which can lead irreversible decomposition of ceria based materials .
Perovskite-structured oxide ion conductors
According to the literature reports, some doped perovskite (ABO3) materials can serve as solid electrolyte materials for SOFC. Al or Mg doped calcium titanate (CaTiO3) exhibits highest oxide ion conductivity . CaTi0.95Mg0.05O3 and Ca-doped Al2O3 show very high transport number (0.9) with no electronic conductivity in reducing atmospheres. However, they are not suitable for SOFC application due to their lower oxide ion conductivity than that shown by YSZ. This lower conductivity results from limited solid solubility of dopants in these oxides less open crystal structure than fluorite structured YSZ [39,40]. But surprisingly lanthanum strontium gallium magnesium oxide (La0.9Sr0.1Ga0.8Mg0.2O3) showed oxide ion conductivity higher than those of ZrO2-based and CeO2-based ion conductors and lower than that of Bi2O3-based ion conductors [39,40]. This material exhibited oxide ion conduction with limited whole and electronic conduction upto 10-23 atm oxygen partial pressure . But this material does not possess good mechanical strength [42,43]. Bending strengths of La0.9Sr0.1Ga0.8Mg0.2O3 at room temperature and 900°C were 162 ± 14 and 55 ± 11 MPa, respectively, which is not suitable for SOFC application . This material does not show good creep behavior . It showed thermal expansion coefficient of 11.5 x 10-6/K down from the room temperature to 1000°C, which is compatible with other components of SOFC .
Brownmillerite-structured oxide ion conductors
This material has a general formula of A2B´B”O5 or A2B2O5. This is a perovskite structured material with one sixth of oxygen sites vacant. The most popular material in this group for SOFC application is Ba2Ln2O5 . Brownmillerites exhibit exhibition conductivity higher than that of fluorite structured oxides . Hole is the major carrier in electrical conduction beyond oxygen partial pressure of 10-3 atm. This material shows a large increase in conductivity at around 900°C. This may be attributed to the transition from oxygen vacancy ordered brownmillerite to oxygen disordered pseudoperovskite structure. This material also shows proton conduction below the temperature of 400°C. Ba2Ln2O5.H2O is responsible for proton conduction [47,48].
Layered aurivillius-structured compounds
Aurivillius compound is a complex oxide system of bismuth and vanadium; the formula of this layer structure is Bi4V2O11-δ . This material shows phase conversion within three phases of α, β and γ over a wide temperature range. This type of material shows conductivity decay upon prolonged heating due to phase separation . This oxide has been modified with the addition of rare earth oxides ( L2O3, where L includes Gd, Er, Dy, Y, Ho, Nd, Sm) . The doped BIMEVOX (BI-Bismuth, ME- dopant metal, V- vanadium, OX-oxygen) gets reduced at low oxygen partial pressure and thereby producing metallic bismuth [52,53] in the following manner:
(Bi2O3)1-x(Me2O3)x → (Bi2O3)1-x-α(Me2O3)x + 2αBi + (3α/2)O2
Therefore, this material does not find application as electrolyte of SOFC.
La2Mo2O9 (LAMOX) is a fast oxygen ion conductor compared to yittria stabilized zirconia materials (YSZ). LAMOX undergoes a reversible phase transition from the nonconductive monoclinic form (α) to the highly conductive cubic (β) form at around 580°C. This phase transition is the primary impediment for this material to find application as a component of SOFC. This material may undergo mechanical breakdown due to repeated cycle of phase transition [54,55]. Praseodymium (Pr) has been used as dopant in LAMOX to suppress its phase transformation, but no suppression occurred; Pr significantly lowers down the phase transition temperature . La2Mo2O9 exhibits high coefficient of thermal expansion of 16.8x10-6 and 13.5x10-6/K at low temperature phase and high temperature phase , respectively, which are not compatible with those of other components . Its ionic conductivity is 2.6 x 10-2 S/cm, which is higher than YSZ materials [57,58]. Molybdenum is prone to reduction in low oxygen pressure . This is the drawback of this material. The ionic transference number of La2Mo2O9 is high (around 0.98) in moderate reducing atmosphere, but it showed phase conversion at oxygen partial pressure of 10-8 Pa at 800°C .
Apatite structured oxides, such as La10Si6O27, La10Ge6O27, etc., exhibits oxide ion conductivity [60,61]. It shows consistent oxide ion conductivity over a wide range of oxygen partial pressure from 1 to 10-21 atm. These apatite’s exhibit hexagonal symmetry with very open structure which may help in oxide ion conduction while its activation energy is very low. This is the reason for investigating this material. Conductivity of this oxide is not higher than that of 8 mol% YSZ at the temperature higher than 600°C ; this may be the reason for slow research activity on this materials.
This is very recent invention based on LAMOX family [62,54]. General formula of this material is La3MMo2O12, where M indicates In, Ga and Al. La3GaMo2O12 showed highest conductivity among the three different compositions. Their conductivities at 800°C are summarized in Table 2 . The conductivity value of La3GaMo2O12 is higher than that of 8 mol% YSZ . The main drawback of LAMOX material was its very high CTE which is not suitable for SOFC. LAMOX doped with In showed the lowest CTE of average 14.7x10-6/K and 12.7x10-6/K for high temperature and low temperature phases, respectively  and higher than that of 8 mol% YSZ . All the three materials (doped with In, Ga and Al) showed phase transformation at high temperatures leading to change in unit cell volume  which is detrimental for their use with other components of SOFC at the temperature of its operation (Figure 1).
|La3GaMo2O12||3.6 x 10-2|
|La3AlMo2O12||2.4 x 10-2|
|La3InMo2O12||3.6 x 10-3|
Table 2: Conductivity Data of La2MMo2O12 Family.
LAMOX family suffers from phase transition especially due to molybdenum (Mo) ; it has been tried to overcome by introducing tungsten(W) in place of Mo. Reducibility of W is less compared to that of Mo [64,65]. W was chosen in place of Mo on the basis of their similar ionic radii (0.59Å for Mo6+ and 0.6Å for W6+) anticipating that 80% solid solubility can be achieved . However, triclinic La2W2O9 (room temperature phase) undergoes reversible phase transition at 1070°C ; therefore, the problem has not been solved with this replacement. However, the problem was tried to be solved with the partial substitution of La and W by Ba and V . The maximum conductivity of 0.011 and 0.006 S/cm were obtained for Ba0.2 substitution in place of La and for V0.3 substitution in place of W while it is 0.032 S/cm for LAMOX at 650°C . Therefore, the result obtained was not so satisfactory.
Proton conducting oxides
Some perovskite oxides exhibit proton conduction in hydrogen containing environment at high temperature . The primary compounds such as BaZrO3, BaCeO3, SrCeO3, SrZrO3 and CaZrO3, are not good conductor; they show good conduction property when doped with rare earth ions such as yittrium (Y) or ytterbium (Yb) due to the presence of electron hole. The reaction takes place in the following manner :
H2 + 2h. = 2H+
where h. symbolizes hole.
SrCeO3 doped with Yb (5 mol%) was studied and the obtained conductivity was around 0.002 S/cm in a humidified atmosphere, which is far below the conductivity of 8 mol% YSZ [70-72]. Proton conduction increases in the following manner: BaCeO3>SrCeO3>SrZrO3>CaZrO3. This trend gets reversed upto SrZrO3 when chemical compatibility comes into consideration. Other proton conducting materials are BaThO3 and BaTbO3 doped with gadolia [73,74], BaTh0.9Ga0.1O3, Sr2Gd2O5 and Sr2Dy2O5 . Maximum proton conductivity obtained was 8.7x10-2 S/ cm at 550°C. The main advantage of this material is that fuel cell does not require water removing unit because proton conductor generate steam in oxidant electrode . Chemical stability of the materials has to be improved. They disintegrate in carbon dioxide and moisture containing environment. Therefore, researchers are trying to make solid solution (as for example, BaZrO3- BaCeO3) to extract good properties of both the materials as well as to avoid their detrimental properties. However, these materials also have the problem of phase separation after a long term use. To address this problem, amount of dopant level is being tried to adjust. BaO evaporation at high temperature is another problem; this is dealt with reduction in sintering temperature. These materials are very hard to sinter, therefore high temperature is necessary. In these materials grain boundaries act as the trap for proton; therefore, reduction of grain boundaries is another technical aspects, which requires very high temperature. Therefore, the problems associated with these materials will take a long time to be properly solved.
Presently research work is being carried out for YSZ, doped CeO2, doped BaZrO3, BaCeO3 and doped BaZrO3- BaCeO3 solid solution. Researchers are putting their effort in developing thin electrolytes. They are developing many techniques like pulse laser deposition, chemical solution deposition technique, etc. for the ordered arrangement of electrolyte molecules in a thin layer without leaving any void in the layer to maintain gas tightness.
The authors’ sincere thanks go to the senior scientists and junior students of High Temperature Energy Materials Centre, Korea Institute of Science and Technology, Seoul, South Korea.
