In-vitro Antimicrobial Activity of Essential Oils and Different Organic Extracts of Lippia alba
Received Date: Feb 15, 2018 / Accepted Date: Feb 21, 2018 / Published Date: Feb 28, 2018
The aim of this study was to investigate antibacterial activity of essential oils and different organic extractives extracted from the medicinal plant Lippia alba. The chemical composition of the hydrodistilled oil was determined by GC-MS spectroscopy. Typical eighty eight components representing 96.14% of the total oil was identified of which spathulenol (3.03%), caryophyllene oxide (6.39%), aromadendrene oxide-(2) (2.82%), alloaromadendrene oxide-(1) (2.46%), ledene oxide-(ii) (2.8%), α-caryophyllene, (1R)-(-)-myrtenal, 1-octen-3-ol (2.77 at.%), 1H-cyclopenta[1,3] cycloprop[1,2]benzene and myrtenyl acetates (3.29%) were the major components. The antibacterial activity was determined in vitro using agar diffusion method and the MIC determination test against six pathogenic bacteria. The essential oils and different extracts (5.0 μL disc–1 correspond to 500 and 250 μg disc–1) displayed a great potential of antibacterial activity against Gram-positive (Sarcina lutea, Bacillus subtilis) and Gram-negative bacteria (Xanthomonas campestries, Escherichia coli, Pseudomonas sp. and Klebsiella preumoniae). The zones of inhibition of different concentrations of the essential oils and the extracts against the tested bacteria were found in the range of 6~23 mm and the minimum inhibitory concentrations (MIC) were recorded between 1.95~500 μg disc–1. The results obtained from this study demonstrated that the natural product derived from Lippia alba might be used in pharmaceutical, cosmetic and agro-industries as natural preservatives or flavoring to control pathogenic microbes.
Keywords: Lippia alba; Essential oils; Organic extracts; Antibacterial activity; GC-MS spectroscopy
Medicinal plants are an important therapeutic aid for various ailments. Different scientific experiments such as biological activity, medicinal and/or antimicrobial properties on the plant components were first documented in the late 19th century . In the light of herbal medication, Bangladesh possesses a rich flora of medicinal plants. Out of 5000 species of phanerogams and pteridophytes, more than a thousand are regarded as having medicinal properties and more than 500 of such medicinal plants have so far been enlisted as growing in Bangladesh .
Over the past 20 years, there has been an increased interest in the investigation of natural materials as sources of new antibacterial agents. In the recent years, the development of resistance of pathogens such as Staphylococcus aureus, Streptococcus pneumoniae, Streptococcus pyogenes, Enterococcus faecalis, Escherichia coli, Klebsiella pneumonia, Pseudomonas aeruginosa etc. against antibiotics has become a difficult issue caused by the indiscriminate use of modern antibiotics [3-5]. Furthermore, methicillin-resistant Staphylococcus aureus (MRSA), penicillin-resistant Pneumococcus, vancomycin-resistant Enterococcus faecalis (VRE), and multidrug-resistant Mycobacterium tuberculosis (MDRTB) are now commonplace pathogens that are proving difficult to treat effectively . Thus, it is urgent need to find out new antimicrobial agents. This demand has driven scientists to investigate the effectiveness of inhibitory compounds such as essential oils, and extracts from plants. Thus essential oils and plant extracts are promising natural antimicrobial agents with potential applications in food, pharmaceutical and/or agro industries for controlling of various pathogens and spoiling bacteria .
Lippia alba (Mill.) N.E. belongs to the Verbenaceae family. It is abundantly present in tropical and subtropical regions including south of the United States of America (Florida), north of Argentina, Australia, India and Bangladesh [8-10]. Leaves are used as an infusion against states of excitement, hypertension, digestive troubles, nausea and cold, to heal wounds sore throat and flu and as syrup against cough and bronchitis. An infusion of the roots is also used against bad colds and coughs. It has also been used as a sedative, against hypertension, flatulence and pain , stomach ache , diarrhea , anaemia , skin diseases (macerate is used for washing), headaches (the plant is crushed and used as a poultice). Beside these, this plant also have cytotoxic, antioxidant, anti-inflammatory, neurosedative , analgesic, antiprotozoal , antiviral, antifungal and antibacterial activities .
In this study, we examined the chemical composition of the essential oils extracted from the leaves of Lippia alba by GC–MS spectroscopy and tested the antibacterial efficacy of the essential oils and various organic extracts with emphasis for the possible future use of the extracts as an alternative to the chemical bactericides.
Materials And Methods
All the chemicals used in this study were of analytical grade. Ethanol, methanol, chloroform, petroleum ether, petroleum sprit, ethyl acetate, dichloromethane were purchased from Merk, Germany and Fluka. Before use, all the solvents were further purified by distillation.
Healthy, disease free, mature Lippia alba leaves were collected from the Islamic University, campus, Kustia, Bangladesh in the period of December. A typical image of the plant is shown in Figure 1. The plant was identified and confirmed by Prof. Dr. Oliur Rahman, Department of Botany, Dhaka University, Bangladesh. The air dried leaves (200.0 g) of Lippia alba were subjected to hydro distillation chamber for 3 hrs using a clevenger type apparatus. The oil was dried over anhydrous Na2SO4 and preserved in a sealed vial at 4°C until further analysis.
In the course of extraction process, the air dried leaves of Lippia alba were pulverized into powdered form and then the dried powder (50.0 g) was then extracted with ethanol, methanol, chloroform, petroleum ether, petroleum spirit, ethyl acetate and dichloromethane separately at room temperature for 7 days. The obtained extract is then named as ethanol, methanol, chloroform, petroleum ether, petroleum spirit, ethyl acetate and dichloromethane extracts, respectively. The organic solvents were evaporated by vacuum rotary evaporator at 50°C
The GC-MS spectrum for the essential oil of Lippia alba was carried out using total ion monitoring mode on a Varian 3800 gas chromatograph interfaced to a Varian Saturn ion trap 2200 GC-MS spectrometer. The temperatures of the transfer line and ion source were 280°C and 275°C, respectively. Ions were obtained by electron ionization mode. The VF-5 capillary column (30 m length, 0.25 mm I.D. and 0.25 μm film thickness) was used. A 20% split injection mode was selected with a solvent delay time of 3 min with injection volume 0.20 μL. The initial column temperature was started at 50°C for 1 min, programmed at 8°C min-1 to 200°C and heated until 280°C at 10°C min- 1. Injection port was set at 250°C. Helium was used as the carrier gas at a constant flow rate of 1.0 mL min-1. Molecular ions (mass range: 40 to 500 mz-1) were monitored for identification. The relative percentage of the oil constituents was expressed as percentage by peak area normalization.
Identification of components of the essential oil was based on their retention indices, relative to a homologous series of n-alkane (C8 to C20) on the VF-5 capillary column under the same operating conditions and computer matching with the GC-MS spectra from the Wiley 6.0 MS data.
The following six microorganisms such as: (i) Sarcina lutea (IFO 3232), (ii) Bacillus subtilis (IFO 3026), (iii) Escherichia coli (IFO 3007), (iv) Pseudomonas sp. (ATCC 13867), (v) Klebsiella pneumoniae (ATCC 10031) and (vi) Xanthomonas campestries (IAM 1671) were used in the antibacterial test. The strains were provided by Prof. Yong Se Lee, Department of Bioresource Technology, College of Agriculture and Environmental Science, Daegu University, Korea. Cultures of the each bacterial strain were maintained on Luria-Bertani (LB) agar medium at 4°C.
The dried extracts were dissolved in the same solvent used for their extraction and sterilized by filtration using 0.22 μm sterile millipore filter (Millipore Corp., Billerica, MA, USA). The antibacterial test was carried out by the agar disk diffusion method with little modification . The test was done using 100.0 μL of standardized inoculum suspension containing 107 CFU mL-1 of the bacteria. The essential oil was diluted 1:5 (v/v) with methanol and aliquots of 15.0 μL were spotted onto the sterile Whatman No. 1 filter paper disks (6.0 mm diameter); while 10.0 μL of 30.0 mg mL-1 of each organic extract (300 μg disk-1) was applied on the filter paper disks and placed on the inoculated LB agar. Negative controls were prepared using the same solvents employed to dissolve the samples. Standard antibiotic, streptomycin (20 μg disk-1 from Sigma- Aldrich Co., St. Louis, MO, USA) was used as positive control for the tested bacteria. The plates were incubated micro aerobically at 37°C for 24 hrs. Antibacterial activity was evaluated by measuring the diameter of the zones of inhibition against the tested bacteria. Each assay in this experiment was replicated three times.
Minimum inhibitory concentrations (MICs) of the samples were tested by the standard NCCL method with little modification . Active cultures for MIC determination were prepared by transforming a loopful of cells from stock cultures to flasks and inoculated in LB medium and incubated at 37°C for 24 hrs. The cultures were diluted with fresh LB broth to achieve optical density of 107 CFU mL-1 for the test organisms at 600 nm by UV/Vis Spectrophotometer (Optizen 2120UV and Optizen III.) Dilutions, to get the final concentrations ranging from 0 to 1000.0 μg.mL-1 of essential oil and various organic extracts in Luria-Bertani broth medium, were prepared in 96 well microplates. Finally, 20.0 μL inoculum of each bacterial strain (107 CFU mL-1) was inoculated onto the microplates and the tests were performed in a volume of 200.0 μL. The plates were incubated at 37°C for 24 hrs. The lowest concentrations of the test samples, which did not show any visual growth of test organisms after macroscopic evaluation, were determined as MICs, which were expressed in μg mL-1. The MICs were measured for the oils and various extractives, as well as for standards of pure compounds a-humulene, spathuleno and eugenol, which were tested on the same cultures under identical conditions to compare their activity with those of the investigated oil and extracts.
The statistical analysis of the essential oil and the different extracts were assayed for antibacterial activity. Each experiment was run in triplicate, and mean values were calculated. The statistical analysis was carried out employing one way ANOVA (p<0.05). A statistical package (SPSS version 11.0) was used for the data analysis.
Results And Discussion
The chemical composition of the essential oil of L. alba extracted by hydrodistilled process was analyzed by GC-MS spectroscopic method. Typical eighty-eight (88) components representing 96.14% of the total essential oil were identified. The results, components with atomic percentage (%) and possible names are tabularized in (Table 1).
|No.||Name of compounds||Retention time (Rt)||Composition (at.%)||No.||Name of compounds||Retention time (Rt)||Composition (at.%)|
|12||2-Cyclohexen-1-ol, 4-ethyl-1,4,dimethyl-||9.041||0.4||56||Aromadendrene oxide -(2)||16.265||2.82|
|29||Acetic acid,1,7,7-trimethyl-bicyclo[2.2||12.328||0.4||73||Alloaromadendrene oxide-(1)||19.537||2.46|
|40||2,6-Octadien-1-ol,3,7-dimethyl-,acetat||13.771||2.4||84||1,2-Benzenedicarboxylic acid,butyl 2-me||22.692||0.27|
Table 1: Chemical composition of the essential oil obtained from the GC-MS spectrum of the medicinal plant Lippia alba.
The antibacterial activity of essential oil, different extractives of Lippia alba against the employed bacteria were qualitatively assessed by the presence or absence of inhibition zones. The results are shown in (Table 2). The essential oil exhibited antibacterial activity against two Gram-positive and four Gram-negative bacteria at the concentrations of 15.0 μL of 1:5 (v/v) dilution with MeOH. The oil exhibited a potent inhibitory effect against Pseudomonas sp., E. coli, K. pneumoniae, B. subtilis, X. campestries and S. lutea, with diameter of inhibition zones ranging from of 9.0 to 22.0 mm. Also ethanol, methanol, chloroform, petroleum ether, petroleum spirit, ethyl acetate and dichloromethane extracts of L. alba revealed a great potential of antibacterial activity against all the bacteria at the concentrations of 500.0 μg disk-1. Methanol and petroleum spirit extracts showed the strongest antibacterial effect against S. lutea, B. subtilis, E. coli and X. campestries with the inhibition zones of 22.0 to 9.0 mm. On the other hand, ethanol, ethyl acetate and dichloromethane extract showed moderate to high antibacterial effects against most of the bacteria that have being tested with the inhibition zones of 9.0 to 15.0 mm. Chloroform and petroleum ether fraction displayed a moderate inhibitory effect against most of the bacteria.
|Pathogens||Zone of inhibition (mm)|
|EtOH=Ethanol, MeOH=Methanol, CHCl3=Chloroform, PE=Petroleum ether, PS=petroleum spirit, EtAc= Ethyl-acetate, CH2Cl2=Dichloromethane, EO=Essential oil, NA-30=Nalidixic acid (30 µg disc-1), S=Spathulenol, E=Eugenol.|
Table 2: Antibacterial activity of essential oils, essential components and different extractives of Lippia alba. 500.0 μg of extracts or essentials oil were applied for experiment per disc.
In this study, the oil exhibited half antibacterial activity of nalidixic acid against Gram-positive bacteria. The blind control did not inhibit the growth of the bacteria tested. Methanol and petroleum spirit, extracts showed higher activity compared to that of the ethanol, chloroform, petroleum ether, ethyl acetate and dichloromethane extracts.
The minimum inhibitory concentration (MIC), as shown in (Table 3), for the oils were found to be lower for B. subtilis and Pseudomonas sp. (15.62 μg mL-1). The E. coli, K. pneumoniae and X. campestries (31.25 μg mL-1) have moderate MIC value but it is higher for S. lutea (62.5 μg mL-1). On the other hand, MIC values of the various extracts against the tested bacteria were found to be in the range of 1.95 to 500 μg mL-1 (Table 3). The Gram-negative bacteria were found to be more susceptible to the essential oil and various solvent extracts than Grampositive bacteria. Standard pure compounds such as spathulenol and eugenol were also exhibited potent activity as compared to that of the oils or extractives.
|Pathogens||Zone of inhibition (mm)|
|EtOH=Ethanol, CHCl3=Chloroform, PE=Petroleum ether, PS=petroleum spirit, EtAc=Ethyl acetate, EO=Essential Oil, S=Spathulenol, E=Eugenol.|
Table 3: Minimum inhibitory concentration (MIC) values of different extracts, essential oils, essential components of Lippia alba. 500.0 μg extracts or essential oil components were applied per disc.
In this present study, the essential oils and various extracts of L. alba exhibited potential activity against reference bacterial strains. This activity could be attributed to the essential oils of L. alba and probably related to the high content of oxygen containing monoterpenes, represented mainly by aldehydes and alcohols, such as neral/geranial and nerol/geraniol . In our opinion, major components of the oils, caryophyllene oxide (6.39%), 1H-cyclopenta[1,3]cycloprop[1,2] benzene (5.01%), (1R)-(-)-Myrtenal (4.71%), spathulenol (3.03%) and eugenol have key roles for their antibacterial activities. The antibacterial activities of these compounds have been reported by the others groups [7,20]. Pure compounds such as spathulenol and eugenol showed potent antibacterial activity. Also, the antibacterial activity of individual components of essential oils such as spathulenol and eugenol has been reported previously [7,21]. On the other hand, the components in lower amount such as terpineol, benzaldehydes, elemene, caryophyllene, tricyclo[184.108.40.206(1,6)]undecan-3-ol and cubenol also contributed to the antibacterial activity of the oils [22-27]. It is also possible that the minor components might be involved in some type of synergism with the other active compounds . Furthermore, the antibacterial activity of organic extract could be attributed to the presence of some bioactive phytochemicals such as alkaloids, flavonoids, steroids, tannins, phenolic compounds, diterpenoids, etc. in the L. alba and these findings are in agreement with the previous reports [19,29-33].
The results of this study are promising and show a possible therapeutic alternative to treat various infections caused by pathogenic bacteria. The findings also support the traditional usage of the L. alba plants and suggests that some of the extracts possess compounds with high antibacterial properties. Therefore, new researches have been proposed in order to elucidate the possible action mechanisms involved and to find new bioactive compounds in L. alba in the upcoming near future study.
The authors are grateful to the Chairman of the Department of Applied Chemistry and Chemical Engineering, Islamic University, Bangladesh for giving working facilities and financial supports to run the research smoothly.
- Yadav M, Khan KK (2012) Antimicrobial activity of some ethnomedicinal plants used by tribes of rewa, madhya pradesh. Indian J L Sci 1: 35-38.
- Rahman MS, Khan MMH, Jamal MAHM (2010) Anti-bacterial evaluation and minimum inhibitory concentration analysis of Oxalis corniculata and Ocimum santum against bacterial pathogens. Biotechnology 9: 533-536.
- Rahman S, Parvez AK, Islam R, Khan MH (2011) Antibacterial activity of natural spices on multiple drug resistant escherichia coli isolated from drinking water, bangladesh. Annals of Clin Micro Antimi 10: 10.
- Dash BK, Sultana S, Sultana N (2011) Antibacterial activities of methanol and acetone extracts of fenugreek (Trigonella foenum) and coriander (Coriandrum sativum). Life Sci Med Res LSMR-27: 2-8.
- Okesola AO, Oni AA (2009) Antimicrobial resistance among common bacterial pathogens in south western nigeria. American-Eurasian J Agric & Environ Sci 5: 327-330.
- Goyal P, Kaushik P (2011) In vitro evaluation of antibacterial activity of various crude leaf extracts of indian sacred plant, Ocimum sanctum L. British Micro Res J 1: 70-78.
- Rahman A, Shanta ZS, Rashid MA, Parvin T, Afrin S, Khatun MK, Sattar MA (2016) In vitro antibacterial properties of essential oil and organic extracts of premna integrifolia linn. Arabian J Chem 9: S475-S479.
- Day MD, Andrew Mc TD (2003) The biology and host range of Falconia intermedia (hemiptera: miridae), a potential biological control agent for Lantana camara (verbenaceae) in australia. Bioconl Sci Techno 13: 13-22.
- Singh G, Rao GP, Kapoor PS, Singh OP (2000) Chemical constituents and antifungal activity of Lippia alba mill. leaf essential oil. J Med Aroma Plant Sci 22: 701-703.
- Hennebelle T, Sahpaz S, Joseph H, Bailleul F (2008) Ethnopharmacology of Lippia alba. J Ethnopharmacol 116: 211-222.
- Rodrigues ACC, Guedes MLS (2006) Use of medicinal plants in the village Sapucaia, cross of the souls-Bahia. Brazil J Med Plants 8: 1-7.
- Pinto EPP, Amorozo MCM, Furlan A (2006) Popular knowledge about medicinal plants in rural communities of mata atlantica-itacar'e ba, brazil. Acta Botanica Brasilica 20: 751-762.
- Toscano-Gonz´alez JY (2006) Traditional use of medicinal plants in the village of San Isidro, municipality of San José de Pare-Boyac'a: a preliminary study using quantitative techniques. Colomb Biolog Act 11: 137-146.
- Gazzaneo LRS, de Lucena RFP, de Albuquerque UP (2005) Knowledge and use of medicinal plants by local specialists in a region of atlantic forest in the state of pernambuco (northeastern brazil). J Ethnobio Ethnomedi 1: 1-8.
- Hennebelle T, Sahpaz S, Gressier B, Joseph H, Bailleul F (2007) antioxidant and neurosedative properties of polyphenols and iridoids from Lippia alba. Phytothe Res 22: 256-258.
- Calzada F, Y´epez-Mulia L, Tapia-Contreras A (2007) Effect of Mexican medicinal plant used to treat trichomoniasis on trichomonas vaginalis trophozoites. J Ethnopharm 113: 248-251.
- Zaidan RMRS, Badrul AN, Adlin AR, Norazah A, Zakiah I, et al. (2005) In vitro screening of five local medicinal plants for antibacterial activity using disc diffusion method. Trop Biomed 22:165-170.
- Clyde T (1983) NCCLS standards for antimicrobial susceptibility tests. Lab Med 14: 549-553.
- Oliveira DR, Santos SS, Bizzo HR, Lopes D, Celuta SA, et al. (2006) Ethnopharmacological study of two Lippia species from oriximin´a, brazil. J Ethnopharm 108: 103-108.
- Deba F, Xuan TD, Yasuda M, Tawata S (2008) Chemical composition and antioxidant, antibacterial and antifungal activities of the essential oils from Bidens pilosa Linn. var. radiate. Food Contr 19: 346-352.
- Pichette A, Larouche PL, Lebrun PL, Legault MJ (2006) Composition and antibacterial activity of Abies balsamea essential oil. Phytother Res 20: 371-373.
- Oyedemi SO, Okoh AI, Mabinya LV, Pirochenva G, Afolayan AJ (2009) The proposed mechanism of bactericidal action of eugenol-terpineol and g-terpinene against Listeria monocytogenes, streptococcus pyogenes, proteus vulgaris and Escherichia coli. African J Biotechnol 8: 1280-1286.
- Kim YS, Park SJ, Lee EJ, Cerbo RM, Lee SM, et al. (2008) Antibacterial compounds from rose bengal-sensitized photooxidation of beta-caryophyllene. J Food Sci 73: C540-545.
- Bassole IHN, Nebie R, Savadogo A, Ouattara CT, Barro N, et al. (2005) Composition and antimicrobial activities of the leaf and flower essential oils of Lippia chevalieri and Ocimum canum from Burkina faso. African J Biotechnol 4: 1156-1160.
- Zhenhong L (2011) Chemical analysis of Magnolia liliflora essential oil and its pharmacological function in nursing pregnant women suffering from decubitus ulcer. J Medici Plants Res 5: 2283-2288.
- Zanousi MBP, Azar PA, Raeesi M (2012) Chemical composition and antimicrobial activity of essential oils of different organs of three Artemisia species from iran. J Medici Plants Res 6: 5489-5494.
- Jong H, Kim JH, Chan KL, Mahoney N, Campbell BC (2011) Antifungal activity of redox-active benzaldehydes that target cellular antioxidation. Annals of Clinical Microbio Antimicro 10: 23.
- Marino M, Bersani C, Comi G (2001) Impedance measurements to study the antimicrobial activity of essential oils from Lamiaceae and Compositae. Int J Food Microbiol 67: 187-195.
- Duarte MCT, Figueira GM, Sartoratto A, Rehder VLG, Delarmelina C (2005) Anti-candida activity of brazilian medicinal plants. J Ethnopharm 97: 305-311.
- Ara N, Nur MH, Amran MS, Wahid MII, Ahmed M (2009) In vitro antimicrobial and cytotoxic activities of leaves and flowers extracts from Lippia alba. Pakistan J Biolo Sci 12: 87-90.
- Aguiar JS, Costa MCCD, Nascimento SC, Sena KXFR (2008) Atividade antimicrobial activity of lippia alba (mill.) n. e. brown (verbenaceae). Rev Bras farmacogn 18: 436-440.
- Veras HNH, Campos AR, Rodrigues FFG, Botelho MA, Coutinho HDM, et al. (2011) Enhancement of the antibiotic activity of erythromycin by volatile compounds of Lippia alba (Mill.) N.E. brown against staphylococcus aureus. Pharmacogn Mag 7: 334-337.
- Mamun RANM, Islam MR, Dash BK (2012) In vitro antibacterial effect of bushy matgrass (Lippia alba mill.) extracts. Res J Med Plant 6: 334-340.
